VL210 USB3.0 Hub
浏览次数:3592



VL210是一个第四代先进USB 3.0 Hub控制器。VL210具有四个下行端口:一个USB 3.0和3个USB 2.0端口,每个端口都可以在不需要外挂电源IC就可以实现充电器的功能。VL210拥有先进的CMOS工艺,能够大大降低功耗并在低功耗状态下完全支持USB电源管理。客户可对USB PHY进行自定义,并可以给VL210各种信道提供良好的性能,使得VL210可支持新2.4GHz Radio Friendly mode的USB EMI认证。VL210特点是一个高度灵活的固件架构,给客户提供一个框架用于客户自行开发其他高级功能。

VIA的VL210可工作在Windows,Mac OS X,Linux等系统。VL210还可以兼容非x86的设备和平台,支持USB集线器功能,如智能手机、平板电脑和机顶盒。它适合所有USB集线器应用,如独立的USB集线器,笔记本/ Ultrabook停靠点/ port-replicators,台式电脑前面板,二合一平板电脑,和USB集线器复合设备。

VL210集成了过流保护电路,GPIO、LED控制,SPI接口还可支持USB更新EEPROM/Flash ROM,是一个设计具有高水准、简洁的布局设计和简化的BOM成本的完美设计。

VL210


- Compliant to USB 3.0 specification revision 1.0, and USB specification revision 2.0

- Fully integrated single chip implementation

- One up-stream supports Super-speed, high-speed and full-speed traffic

- Four down-stream ports; one port supports Super-speed, high-speed and full-speed traffic, and three ports support high-speed and full-speed traffic

- Charging Downstream Port(CDP), feature for rapid-charging

- In-house USB PHY employs advanced CMOS process for  low power consumption

- Supports USB 3.0 low power states

- Supports full sideband signal functions include gang mode and LED status lights



- Full software support for Windows 8, 7, Vista, XP, 2003, 2000, ME and Mac OS 10X and various Linux kernels
